ED BSP – Cross-Laminated Construction Panels

Description

ED BSP | Cross-Laminated Construction Panels are solid timber elements, ideal for the construction of load-bearing or non-load-bearing walls, floors, and roofs. Made up of 3 to 9 layers of cross-laminated and bonded lamellas, these panels offer exceptional stability, excellent mechanical resistance, and remarkable ecological performance. The large-format elements are cut and shaped with precision using CNC machines, ensuring a perfect fit to modern architectural needs. Characteristics Species: Solid timber artificially dried to 12% ± 3%. Panel thickness: From 63 mm to 292 mm. Structure: Symmetrically cross-laminated and bonded lamellas, increasing stability and static capacity. Certification: French technical assessment (CSTB) and ETA-12/0327. Treatment: Drying, planing, and partial finger-jointing of the lamellas. Physical properties: Good thermal insulation, open diffusion, and excellent protection against heat and noise. Advantages Static performance: High resistance thanks to the cross-lamination of the lamellas. Suitable for seismic zones. Planning and precision: CNC cutting for a perfect fit. Architectural flexibility for modern and customized shapes. Ecology and sustainability: Sustainable construction and low energy footprint. CO2-accumulating construction material. Interior comfort: Good indoor climate, with optimal regulation of heat and humidity. No vapor barrier required thanks to an open-diffusion structure. Fast and economical assembly: Prefabricated elements reducing installation time and costs. Dry construction allowing fast installation. Applications Construction of load-bearing and non-load-bearing walls. Floors and roofs in residential, commercial, and industrial buildings. Projects requiring high structural rigidity and optimal thermal insulation. Vertical extensions thanks to the reduced weight of the elements.

Caractéristiques techniques
