HW insert shank tool body LEUCO

Description

HW insert shank tool body LEUCO is aimed at CNC machines. The tool is used for pre-milling and routing in coated wood-based materials and for angled plunging with simultaneous use of the Z and X or Y axes. In terms of design, LEUCO provides: upper and lower insert with axial angle, cutting material: HW HL Board 05, cutting material: HW HL Board 03 and with stop screw. Advantages highlighted by LEUCO: high performance and chip-free edges. The range comes in 1 version: outside diameter of 22 mm, shank of 25 mm, overall length of 131 mm and 1 tooth. Cutting material: carbide (HW). To consider before ordering: clamping: ps-System, TRIBOS, collet chuck, and with stop screw.
