HW insert shank tool body, Z=2+2, direction of rotation L+R

Description

HW insert shank tool body, Z=2+2, direction of rotation L+R is aimed at CNC machines. The tool is used for facing, rebating and grooving in solid wood and wood-based materials and for trimming and milling circular cut-outs. In terms of design, LEUCO provides: a right-hand or left-hand rotating cut with axial angle for breakout-free edges on the top of the panel, by moving the Z axis and changing the direction of rotation the lower part of the cutting edge can be used in left-hand rotation, an option that avoids a tool change when pre-machining the corners exposed to breakout, and with stop screw. The range comes in 1 version: outside diameter of 20 mm, shank of 25 mm, overall length of 130 mm and 2 teeth. Cutting material: carbide (HW). To consider before ordering: the workpiece is clamped on blocks, clamping: ps-System, TRIBOS, collet chuck, and with stop screw.
